Ultra miniaturized technology
Digital optical holography

 We develop
 innovative technology

with the aim of miniaturizing a complete 3D color camera module to the fraction of a fingernail in order to support various markets (with a focus on medical technology). The hardware is reduced to the physical limit by using the most advanced opto-electronic elements, while at the same time the data algorithms use increasingly powerful processors and ASICS. Ultra miniaturization, very good performance data and cost-effective production are then no longer mutual exclusion criteria.

Above all, our vision is to open a new technological door, according to the motto:
"Jump and grow your wings" (Ray Bradbury).

Dr. Alexander Knüttel

Our technology

Optical interference methods

AKmira optronics develops miniaturized 3D color camera modules which, together with rod optics, form rigid 3D endoscopes. The primary area of application will initially be medical technology. The integration of the ultra-miniaturized 3D camera modules in flexible endoscopes is planned as an extension. The possibility of integrating this technology into very small units such as mobile phones and 3D data glasses in the future will open up further markets for security technology and augmented reality. The underlying - in the non-academic environment - new technology is based on digital, optical holography and this is an extension of the well-known interference methods such as OCT (Optical Coherence Tomography) or interference microscopy. AKmira has its own innovative approaches that fully utilize the potential of digital, optical holography. This technology is protected by 4 AKmira registered patents.

 Advantages of digital
 optical holography

Extremes Miniaturisierungspotenzial

Die Minimierung an Hardware und Nutzung modernster opto-elektronischer Komponenten bei gleichzeitig effizienterer Rechenleistung ermöglichen Leistungsmerkmale bis an physikalische Grenzen

Extremes Miniaturisierungspotenzial

Keine mechanische Refokussierung

Keine mechanische Refokussierung

Die Technologie erlaubt auf mechanisch bewegte Teile zu verzichten und auf verschiedene z-Distanzen mittels entsprechender Algorithmen zu fokussieren um ein 3D Farbbild zu ermitteln

Präzises optisches „stitching“

Präzises optisches „stitching“

Durch die Möglichkeit 3D Features in Einzelbildern mit µm-Genauigkeit zu erkennen können große 3D Szenen nahtlos aus Einzelbildern zusammengesetzt werden

z-Bestimmung unabhängig vom Abstand

Im Gegensatz zur 3D Stereo-Vision ist die z-Bestimmung unabhängig vom Abstand, da das Laufzeitverhalten der Lichtstrahlen mit µm-Genauigkeit genutzt wird und nicht die prinzipiell ungenauere Winkel-Disparität

z- Bestimmung unabhängig vom Abstand

Optional: Sub-Surface Messungen bis 3 mm

Durch den Einsatz von multiplen Laserwellenlängen im nahen Infrarot sind bis etwa 3 mm unterhalb der Gewebeoberfläche genaue Abstandsmessungen auf z.B. einen Knochen oder einer Zahnoberfläche möglich

Optional: Sub-Surface Messungen bis 3 mm

Lokales 3D Operations-Mikroskop

Lokales 3D Operations-Mikroskop

Die hohe laterale Auflösung der Einzelbilder unserer sehr kompakten und flexibel einsetzbaren 3D Kamera macht aus dieser ein lokales Operations-Mikroskop.

We are looking for strong business partnerships in strategic development and global sales.

Future areas of application

The image shows a futuristic representation of a brain operation with 2 doctors and is intended to show the area of ​​application in medical technology for the ultra-miniaturized 3D endoscopy camera technology from AKmira Optronics.

Medical technology

The initially targeted area of application will be rigid endoscopy for 3D applications. With further miniaturization, integration into the tip of a flexible endoscope will be possible. In addition AI-driven applications for "robot-assisted surgery" with mini endoscopes will be considered.

The image shows a futuristic fingerprint and is intended to show the area of ​​application in security technology for the ultra-miniaturized 3D endoscopy camera technology from AKmira Optronics.

Safety technology

As miniaturization progresses, integration into a mobile phone, for example, is possible. This means, that a 3D fingerprint can be recognized without contact and with protection against forgery, since the 3D micro-movement (“trembling”) can be evaluated simultaneously.

The image shows a medical employee wearing transparent augmented reality glasses and is intended to show the area of ​​application in augmented reality of the ultra miniaturized 3D endoscopy camera technology from AKmira Optronics.

Augmented reality

Integration into “Augmented Reality” glasses is also possible as miniaturization progresses. This allows certain things to be optically captured very sharply in 3D, indipendent of z-distance, and then presented to the viewer via corresponding glasses for 3D "overlay" visualization.

Golden Eye

The heart of 3D camera technology

Currently exists a 3D endoscope with a rigid endoscope tip diameter of 7 mm. The prototype of generation 1 (Gen. 1) 3D camera technology is integrated in the housing. Another generation (Gen. 2) will already be significantly more compact and the 3D camera technology will fit the size of a 1 cent coin.
From this generation on, the sub-surface option can be permanently integrated. In the ultimate expansion stage (Gen. 3), the 3D camera will encompass a fraction of a 1 cent coin or a fingernail as the "Golden Eye".

GEN 1

Generation 1 | prototype, presented at the Medica Düsseldorf 14.-17.11.2022

GEN 2

Generation 2 | compact opto-electronic camera-modul to integrate in an mini-endoscope

GEN 3

Generation 3 | Golden Eye becomes ultra small and integrable in multiple fields of application

Golden Eye

The heart of 3D camera technology

Currently exists a 3D endoscope with a rigid endoscope tip diameter of 7 mm. The prototype of generation 1 (Gen. 1) 3D camera technology is integrated in the housing. Another generation (Gen. 2) will already be significantly more compact and the 3D camera technology will fit the size of a 1 cent coin.
From this generation on, the sub-surface option can be permanently integrated. In the ultimate expansion stage (Gen. 3), the 3D camera will encompass a fraction of a 1 cent coin or a fingernail as the "Golden Eye".
The picture shows the camera model of the 3D Holography Golden Eye from AKmira Optronics in the first generation.

GEN 1

Generation 1 | prototype, presented at the Medica Düsseldorf 14.-17.11.2022

The graphic visualization shows the tiny size of the 3D Golden Eye camera generation 2 from AKmira Optronics in relation to a 1 cent coin.

GEN 2

Generation 2 | compact opto-electronic camera-modul to integrate in an mini-endoscope

The graphic shows the 3D visualization of the 3D holography of a human heart recorded with the 3rd generation Golden Eye camera technology from AKmira Optronics.

GEN 3

Generation 3 | Golden Eye becomes ultra small and integrable in multiple fields of application


Skin image from the back of a hand


Image from a fingerprint skin texture


Image of 2 lower front teeth and gum
